Great shop runs are decided long before you hit Start. If your drawings live on one monitor, job specs hide behind windows and a USB stick dangles off the desk, mistakes creep in—wrong origin, missed kerf, out‑of‑date toolpaths. A height‑adjustable standing desk can anchor a calm, repeatable prep station for CNC routers and laser cutters, keeping posture honest while you move from CAD to CAM to a clean shop handoff. This practical guide covers screen layout, file checks, job travelers, networking and cable management (plus a few safety reminders) so your work reaches the machine exactly as intended.

Set the geometry first (your back will thank you)

• Eye line and distance: Keep the top third of the primary display at or slightly below eye level, about an arm’s length away. A monitor arm lets you make fine changes without chasing height with the desk.

• Two‑screen logic: Center CAD/CAM on the primary. Put the job traveler—material, tool, origin, power/speed, notes—on the secondary screen angled inward 15–30 degrees. You’ll glance with your eyes, not twist your torso.

• Typing plane: In Sit or Stand, elbows hover near 90 degrees, shoulders relaxed, wrists straight. If wrists extend during long CAM passes, lower your height‑adjustable standing desk by 0.25 inch or add a slight negative keyboard tilt.

Task‑based presets that track your prep flow

Save four memory buttons so posture changes are one tap.

• Model (Type; slightly lower): Wrist‑neutral height for CAD edits, constraints and layers.

• Check (Stand): General standing height for CAM toolpath previews, clearance checks and material verification. Standing improves vigilance.

• Release (Stand): Same height for sending to the controller or exporting to the server/USB, with the job traveler visible.

• Notes (Sit): Seated height for documentation, change logs and revision notes.

From CAD to CAM: a repeatable checklist

• Units and scale: Confirm model units and the CAM post’s units match. Wrong units are a classic time sink.

• Origin and stock: Define a sensible origin (router: typically a stock corner or center; laser: table corner or material corner). Note it on the traveler.

• Layers and colors: Separate cut/score/engrave (laser) or pocket/profile/slot (CNC). Lock reference and fixture layers so CAM ops can’t select them.

• Kerf/offsets: For lasers, compensate for kerf in‑or‑out depending on inside vs. outside contours. For CNC, set cutter compensation and verify tool diameter in the library.

• Inside before outside: Order paths so internal features cut before perimeter to keep parts anchored.

• Tabs/bridges and hold‑downs: Add tabs or bridges where needed (router), and document fixtures or masking (laser).

• Lead‑ins/outs: Use appropriate leads to minimize marks, especially on visible edges. For lasers, mind start points on corners.

• Tool selection (CNC): Verify tool number, diameter, flute count, step‑over, stickout. Match feeds/speeds to material and cutter. Preview chip load in your CAM.

• Operation parameters (laser): Power, speed, frequency (if applicable), passes, focus height, air assist. Confirm material library entries against a known test coupon.

• Simulation and collisions: Run a full toolpath simulation. For routers, check retract height, clamps and stock thickness. For lasers, check that layers are set to cut/score/engrave as intended.

The job traveler: shop‑ready, no surprises

Create a one‑page traveler (print or PDF/QR) that follows the job:

• Part name, revision, date, operator.

• Material: species/alloy, sheet thickness, stock size, mask (Y/N).

• Origin and zero: table corner or stock center; Z‑zero surface; fixture notes.

• CNC: tool numbers, speeds/feeds, pass depths, coolant/air.

• Laser: power/speed/frequency, passes, focus height, air assist.

• File locations: server path or USB label; post‑processor used.

• Checklist: “Inside before outside,” “Tabs confirmed,” “Kerf/offset verified,” “Focus/zero confirmed,” “Test coupon cut” (laser).

Mount this on the secondary screen while you prep so you can check boxes as you go. Export the final PDF with your files so the shop has the same truth.

Networking and file hygiene (skip the thumb‑drive roulette)

• Wired uplink: Run a stranded Cat6/Cat6a patch through a leg raceway to a tray‑mounted switch or your dock. Wired links are steadier than Wi‑Fi for big vectors and toolpath posts.

• Versioning: Use a simple naming scheme: Part_Rev_YYYYMMDD.ext. Point the traveler to a read‑only “Release” folder so the shop pulls the exact files you signed off.

• USB discipline (if required): Label sticks by job; eject cleanly; keep them in a shallow caddy—not dangling from a front port. After the run, copy back any controller‑side changes and archive, then wipe.

Lighting and visibility that protect posture

• Desk orientation: Perpendicular to windows to reduce screen glare that quietly pushes your chin forward.

• Task and bias: A dimmable task lamp aimed at paper (not the screens) reduces reflections; a subtle bias light behind the monitors softens contrast for evening checks.

• Brightness parity: Match brightness/white point across both screens so one doesn’t “pull” your gaze and nudge your head forward.

Dust‑adjacent realities: protect the desk and cables

• Location: Keep the standing‑desk prep station outside the dusty zone. If you’re near a shop, vacuum weekly and keep the cable tray closed.

• One‑cord power: Mount a surge‑protected strip and your dock in a metal cable tray under the top. Route a single mains cable down an inside leg raceway to the wall. No diagonal floor runs to catch shoes or carts.

• Service loops: Above the tray, create gentle U‑shaped slack for every moving line—display power/video, Ethernet, USB‑C to laptop, task lamp, camera. Each loop must reach max standing height plus an inch or two. Test full up/down.

Safety and common‑sense reminders (nonlegal, non‑medical)

• PPE and ventilation belong in the shop. This page is about prep, not machine operation; follow your shop’s safety policies for cutting, fume extraction and eye/ear protection.

• Liquids: Keep drinks and solvents away from the rear edge where the power tray lives.

• Anti‑collision: Enable the desk’s anti‑collision and test monthly with a soft block; lock the keypad if students or visitors share the space.

A 10‑minute pre‑release routine you can trust

1. Tap Check (Stand). Confirm units, origin, stock, offset/kerf, op order.

2. Run simulate. Verify retracts, clamps, tabs, lead‑ins/outs.

3. Fill traveler. Material, origin, tools or power/speed, file locations.

4. Export. Use the right post‑processor; drop into a Release folder; print or save the traveler.

5. Tap Release (Stand). Send to controller/server or copy to labeled USB; verify receipt.

6. Tap Notes (Sit). Log changes; bump revision if needed.

Troubleshooting the usual gremlins

• Parts undersize (laser): Kerf not compensated. Add kerf offset (outside paths negative/inside positive by half kerf), or tweak library after a test coupon. Document on the traveler.

• Tabs missing (router): Wrong operation order or selected contours. Re‑select geometry, ensure inside features precede perimeter, regenerate toolpaths.

• Wrong origin at the machine: CAM origin didn’t match the controller. Put a big origin diagram on the traveler; re‑zero and re‑post.

• Screen wobble at full height: Retorque frame/arm joints, bring monitors closer to the columns and lower panels by 0.5 inch; verify feet are level (use firm pads on carpet).

A CNC/laser prep checklist (print this)

• Geometry: Primary CAD/CAM centered; traveler on secondary angled inward; both screens at eye line and arm’s length.

• Presets: Model (lower), Check (stand), Release (stand), Notes (sit) saved and labeled.

• CAD/CAM: Units match; origin/stock set; layers clean; kerf/cutter comp verified; inside‑then‑outside; tabs/bridges; lead‑ins/outs; simulation OK.

• Parameters: Laser power/speed/frequency, passes, focus, air assist; or CNC tools, feeds/speeds, step‑downs, retracts.

• Traveler: Material, origin, parameters, file path, post‑processor, checklist items.

• Networking: Ethernet through leg raceway; Release folder; labeled USB (if needed).

• Cables: Surge strip and dock in tray; single mains cable down leg raceway; gentle U‑loops; arm channels first.

A color‑coded CAM library and a good machine help—but what really kills errors is a calm, repeatable prep routine. With a standing desk, you can stand to check and release, lower to model and sit to document—without breaking your flow. Keep job specs visible on a dedicated screen, wire the desk for reliable transfers, and give every cable a safe slack loop so you actually use your presets. Your parts will leave the office ready for the shop, not for rework.
